Specifications
Tests: PT, PTT, TT, FIB, Fa-I (Factor Instrinsic), Fa-E (Factor Extrinsic)

Sample:Plasma

Volumes:quarter of regular volume Volume (e.g. PT: 25μl sample +50μl reagent)

Convertion of seconds in: INR, mg/dl. %

Language: Standard English, others on request

Optic Cell: photometer with pulsed 470nm LED’s, variable pulse modulation, variable detector amplification

Incubation block: 1 measuring, 6 samples, 2 reagent positions

Incubation block temperature: 37,0℃ +/- 0,2℃

Dimensions instrument (LxWxH): 245x130x60 mm

Weight instrument w/o power supply: 0,51kg

Parcel gross weight incl. accessories: 1,6 kg

Ambient temperature: 18-23℃

Powere supply M1: input: 90-240 Vac, 50-60 Hz, output: 12V, 1, 2A

Thermal printer: optional, external, serial printer with print-out of system parameters and results in all selected dimensions

RS232 interface:
Autostart

Standard Package:
1Pc diacheck C1
1Pc Power supply
25 Pcs Single cuvettes
5 Pcs reagent tubes
2 Pcs reagent adaptors
1 Pc operation manual (English)
1 Pc Warranty card
